75W Wall Mount LCD Display Plug In Play 178° Viewing Angle For Hospital

Brand Name : felehoo
Model Number : FH-WU420C
Certification : CE/ROHS/FCC
Place of Origin : China
MOQ : 1pcs
Price : Negotiation
Payment Terms : T/T, Western Union, MoneyGram
Supply Ability : 3000pcs per month
Delivery Time : 5~10 working days after your confirmation
Packaging Details : Packed in carton firstly, reinforced with wooden case as outer package
Product Name : LCD Digital Signage
Panel size : 42"
Max Resolution : 1920 X 1080
Appearance : Iphone type design Enclosure
Viewing angle : 178°/178°/178°/178°
Display area(mm)/mode : 521mm(H) X 927mm(V)
Ad content Update : USB
Power supply : 100 V ~ 240V
Contact Now

75W Wall Mount LCD Display Plug In Play 178° Viewing Angle For Hospital


wall mounted lcd digital signage 42 inch is a LCD Display with an integral media player, Media files are stored and played back from USB or SD card. When you boot the machine up, it would auto read those files (video/photo)from memory card simple one.


1, The reason that you need wall mounted lcd digital signage as follows:


Ad content can be created easily via digital signage which allow advertisers to combine audio, video, image and interactivity by themselves. Digital signage are used for many different purposes. It helps to engage users and also helps advertisers to gain insight in customer behaviors. Ad contents displayed on the signage is presented in one of the following formats:


A, Text - Scrolling text. Either scrolling text, or text dynamically updated via external newsfeed source.

B, Images - Scrolling images, usually in the format of digital advertisement posters.

C, Video - Usually in the format of commercial TV advertisements.


2, The Product Specification :


Panel size42"
Display area(mm)/mode927(H) X 521(V)
Maximum resolution1920 X 1080
Display color16.7M
Pixel Pitch(mm)0.60(H)×0.60(V)
Brightness (nits)450cd/m2
Contrast4000 : 1
Visual angle178/178/178/178°
Response time8ms
Life(hrs)50,000(hrs)
Max Power Consumption75W
The machine body dimension(Lx W x H)mm1030x623x55
Net weight27 kg/pcs
Gross weight45 kg/pcs
Outer Packing size1190x780x240mm

3, Version Options:


We offer you 2 version lcd digital signage for choice.


A) Plug In Play Version (Standalone version)


1, The working Principle of Standalone version lcd digital signage :


The PCB support Plug-and-Play function.You need save those ads content in USB memory card firstly, and then, when you plug memory card into the card slot, the screen will auto display video or photo. When you need update ads content in original USB memory card, you only need use USB copy by manual operation .


2, The specification of internal Standalone version media player


Main FeaturePlug-and play, Auto loop play when power on
ChipsetMCU
RAM512
OSLinux
NetworkNo
Input card slot2 x USB2.0
Storage MediaDefault USB(SD card is optional)
Download MediaAuto copy from USB
External storageSupport 2G ~ 32GB
OSD languageChinese / English
Display EffectSupport 720P/1080P Full HD video/Photo
Support Video FormatsAVI,MPEG1,MPEG2,MPEG4,VOB and DIVX(5.0/6.0)
Support Audio FormatsMP3
Support Photo FormatsJPG
Support Doc formatsTXT
Audio OutputBuilt-in Power amplifer
Playback ModeRepeat one/all, choose to repeat playback one file or all the files
Power SupplyAC 100~240V


B) Internet Based Android version.


1, The working Principle of Android Version lcd digital signage :


About network lcd digital signage, we can offer you the complete solution, not only the hardware but also the software system. The machine with wifi/3g that can auto download content from internet for customer advertising that changes over night to different ads every day via network download. we also offer you our software system to manage all the screens, this means that you can transfer ad files to the screen remotely via wifi or 3g network from your office. The screen will automatically play video and image contents (entertaining and advertising contents), prepared by those content manage from a server, which scheduled ordisplayed for playback through the centralized software, distributed to lcd locations. Each lcd has to be able to automatically detect new contents and start playing them, without any man-work.


2, The specification of internal Android version media player

CPUARM Cortex-A7, 1.2 GHz, Dual core
Infrared remote controlSupport
RAMDDR3 1G byte
Internal MemoryNAND FLASH 8G
External MemorySATA/USB/SD card/CF card
Resolution1080P(1080 X 1920)
Play modeCirculation, timing, inter-cutting etc.
NetworkEthernet, wifi, 3G is optional
Video formatwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
SD cardCompatible for SD card and CF card
Picture formatBMP, JPEG, PNG, GIF
Networking protocolTCP IP/PPPOE/ICMP/DHCP/DNS/FTP/HTTP
USB2.0 port2 x USB HOST external mouse and keyboard
Ethernet/wifi1 x RJ45, 10M/100M optional and 150Mbps 802.11n Wifi
Operating systemAndroid 4.4.2


1, Based on Android 4.4.2 system, all the android application Apk, software automatic restoration supported.
2, Real time management and controlling, browser, breakpoint upload and download, multi-mode upload supported.
3, Updating programs(video,pictures,texts,PPT etc.)through the Internet supported.
4, Auto Power on/off,electroic clock & date supported.
5, Split screen and fixed template display setting supported.
6, Setting IP address, working time and working day supported.
7,1080P Full HD programs display supported.
8, WAN & LAN long-distance setting play/sleep/reboot etc .fuction supported.
9, Display contents cryptographic protection supported(selectable)
10, Cable network, wifi, touch screen, inner camera setting supported(selectable)
Notice : If you don't like our CMS software, you can also install your own Apk in our machine, which means that you can integrate other digital signage player or system software in display.



4, The physical photo :



If you have any other questions, please contact our salesman as soon as possible.




Email : kevin@vcaminition.com


Skype ID : kevin.liu505


Whats App ID : +8618814488091


Wechat ID : felehoo


Twitter ID : Vinition


Facebook ID : kevin518112


Linkedin ID : 18814488091
